-3,69 €Nuevo
Wonlink AC1200/300 punto de acceso al aire libre 5Ghz /2G repetidor de enrutador Wifi de alta potencia extensor Wifi de largo al
Wonlink AC1200/300 punto de acceso al aire libre 5Ghz /2G repetidor de enrutador Wifi de alta potencia extensor Wifi de largo alcance antena Nanostation AP
El total del pedido incluye el IVA
2-4 dias hábiles
Envio gratis
Wonlink AC1200/300 Outdoor Access Point 5Ghz /2G High Power Wifi Router Repeater Long Range Wifi Extender Antenna Nanostation AP
Difference :
WL-AP7202 1200Mbps 2.4 +5.8Ghz 2*5 External Antenna 48V poe Adapter Gigabit Port Support 120 Users +
WL-AP7204 1200Mbps 2.4+5.8Ghz 2*5 External Antenna 24V Poe Adapter Support 60 Users +
CF-EW71 300Mbps 2.4Ghz 2*5 External Antenna 48V Poe Adapter Support 40 Users
Product Description:
WL-AP7202 is a 1200Mbps outdoor high-power AP, using MT7621DAT+MT7613BEN+MT7603E chip solution, Equipped with dual-band PA power amplifier and 128MB large memory, it is an outdoor omnidirectional coverage AP product.
Product Performance Advantage
1200M dual frequency, fast and stable
WL-AP7202 supports 1200Mbps fast wireless rate, can work in 2.4GHz&5.8GHz frequency band, 2.4GHz frequency band has strong diffraction power, 5.8GHz anti-interference is strong, providing users with fast, comprehensive and stable outdoor wireless network.
Three-chip design, stable and reliable products
WL-AP7202 adopts a three-chip solution, MT7621DAT + MT7613BEN + MT7603E chips, and the 2.4GHz&5.8GHz frequency band is equipped with a high-performance independent power amplifier circuit (PA: Power Amplifier), which improves the wireless transceiver performance, and the signal is higher than that of ordinary APs. stronger.
IP66 outdoor protection grade
WL-AP7202 supports IP66 protection level, which can effectively prevent the impact of bad weather such as wind, frost, rain and snow on the equipment, prevent the infiltration of dust and water droplets, and ensure that the equipment can run safely and stably in bad weather.
High gain omnidirectional antenna
WL-AP7202 is equipped with 2* 5dBi dual-band omnidirectional antenna, which supports 360° omnidirectional coverage, and fully meets the long-distance wireless coverage requirements of outdoor squares, stadiums, scenic spots, parks, playgrounds and other environments.
Product Feature
1.Model Number: WL-AP7202
2.Chipset:MT7621DAT +MT7613BEN+MT7603E Chipset ,
3.RAM : 128MB ; Flash : 16MB ;Power amplifier chip: 2.4G KCT8227D;Optional configuration watchdog chip;；
4.Support the maximum number of end users ：120+ (Configure watchdog chip)
5.RF Parameters:200mW (23dBm)Transmitting Power
6.Antenna:2*5dBi dual band Omnidirectional antenna ；
7.Wi-Fi Transmission Rate: 2.4Ghz : 300Mbps , 5.8Ghz : 867Mbps ;Maximum receiving sensitivity ：-96dBmWorking frequency ：802. 11ac/a/n: 5. 180GHz-5.825GHz , 802.11b/g/n : 2.412GHz-2.484GHz ;
8.Physical interface : 1*10/100/1000M LAN RJ45 Ethernet port (Support POE power supply) , 1*10/100/1000M WAN RJ45 Ethernet port (Support POE power supply)1*RESET Button ;
9.Indicator light ：Power / WAN / LAN / WiFi indicators ；
Power supply ：POE power supply Support 802.3af/802.3at standard (Up to 100M ）；48V 0.32A POE power adapter ;
10.Power Consumption:<13W
11.Lightning protection; IP66 Level MTBF:>250000H
12.Installation method :Pole installation, wall installation；
13.Application : Application for park / school / Driving school / Plant area / Shopping mall / Village
Package content:
With retail box
1*AP main body
1*48V POE power adapter
1*O type fixing loop
1*User manual
1*guarantee card
WL-AP7204 1200Mbps Outdoor Access Point
EW71 300Mbps Outdoor Wifi Access Point
12000040002058300
- Producto químico muy preocupado
- Ninguno
- Tipo
- wireless
- Función
- Cortafuegos
- Nombre de la marca
- wonlink
- Origen
- CN(Origen)
- Paquete
- Sí
- Uso
- Al aire libre
- Velocidad de transmisión Wi-Fi de 5 GHz
- 867 MB/s
- Estándar Wifi
- 802.11ac
- Velocidad de transmisión Wi-Fi de 2.4 GHz
- 300 Mbps
- Frecuencia compatible con Wi-Fi
- 2.4G & 5G
- Puertos WAN
- 1x10/100/1000 Mbps
- Puertos LAN
- 1
- Normas y protocolos
- Wi-Fi 802.11b,Wi-Fi 802.11g,Wi-Fi 802.11n,Wi-Fi 802.11ac
- Velocidad máxima de transferencia de la conexión LAN
- 1.000 MB/s
- Con función de módem
- No
- Velocidad de transferencia por cable
- 10 / 100 / 1.000 MB/s
- Compatibilidad WPS
- Sí
- Compatibilidad WDS
- Sí
- Número de interfaces USB
- Ninguno
- Velocidad de transmisión inalámbrica
- 1200 metros
- Malla de soporte
- No compatible
- Frecuencia
- 5 gigahercios
- Tipo de Antena
- Fijo
- Usos recomendados
- Negocios
- Estándar de comunicación inalámbrica
- 802.11ac
- Clase de banda de frecuencia
- Doble banda
